4P Type AC 30mA

RCCBs 4P GO range are suitable to detect earth faults’ currents. In case the installation requires also protection from eventual overload and short-circuits, the RCCBs must be installed in series with MCBs or with fuses.
Type AC RCCBs are recommended to protect those installations where users may imply alternate sinusoidal earth faults.
RCCBs’ functioning is independent from line voltage and the mechanism is trip-free, meaning that RCCBs can also trip when the lever is held on close position. All products can be power supplied from both the top and the bottom terminals. Furthermore “cage” type terminals facilitate connection both through conductors (up to 35mm² rigid and 25mm² flexible) and through busbars (both pin or fork types).
